CONTAINERS

RECYCLING CONTAINERS

Recycling-Containers

25 Yard Shown

FEATURING:
  • Lifetime Guarantee on Hook and Hook Plate
  • Rudco Roll-Offs feature tube main rails with solid bullnose
  • All containers are primed and painted in one of ten standard colors
  • Formed front corner posts for added strength
  • Non-Sagging Door is designed to rest on floor of container
  • Large “V” notches in each vertical support column prevents moisture retention
  • Vertical Lift Handle with Semi-Automatic Cam Locking System
recyclingWireFrontal
recyclingWireProfile
recyclingWireTop

Specifications

SIZE
12 YD

DOORS PER SIDE
2

HEIGHT INSIDE
55"

HEIGHT OUTSIDE
78-1/2"

WIDTH OVERALL
96"

LENGTH OVERALL
(A) 12' 9"

APPROX. WEIGHT
3900 LBS.
SIZE
18 YD

DOORS PER SIDE
3

HEIGHT INSIDE
55"

HEIGHT OUTSIDE
78-1/2"

WIDTH OVERALL
96"

LENGTH OVERALL
(A) 16’ 9”

APPROX. WEIGHT
4500 LBS.
SIZE
25 YD

DOORS PER SIDE
4

HEIGHT INSIDE
55"

HEIGHT OUTSIDE
78-1/2"

WIDTH OVERALL
96”

LENGTH OVERALL
(A) 22’ 9”

APPROX. WEIGHT
5000 LBS.

Specifications

  • 12 YD
    DOORS PER SIDE
    2

    HEIGHT INSIDE
    55"

    HEIGHT OUTSIDE
    78-1/2"

    WIDTH OVERALL
    96"

    LENGTH OVERALL
    (A) 12' 9"

    APPROX. WEIGHT
    3900 LBS.
  • 18 YD
    DOORS PER SIDE
    3

    HEIGHT INSIDE
    55"

    HEIGHT OUTSIDE
    78-1/2"

    WIDTH OVERALL
    96"

    LENGTH OVERALL
    (A) 16’ 9”

    APPROX. WEIGHT
    4500 LBS.
  • 25 YD
    DOORS PER SIDE
    4

    HEIGHT INSIDE
    55"

    HEIGHT OUTSIDE
    78-1/2"

    WIDTH OVERALL
    96”

    LENGTH OVERALL
    (A) 22’ 9”

    APPROX. WEIGHT
    5000 LBS.
STANDARD DECK
  • 3/16” PL. Floor Sheet
  • 3” Structural Channel on 20” Centers
  • 3/16” PL. Gussets on every other Cross Member
  • 6” x 2” x 3/16” Tube One Piece Main Rail
  • Four 8” diameter x 10” LG. Heavy Duty Wheels
  • 4” OD x 6” LG Front Roller w/1½” Pin and Grease Fitting
  • 1” Certifi ed Hook Plate (w/lifetime guarantee)
  • 1¼” Certifi ed Plate Cable Hook (w/lifetime guarantee)
  • 1½” Plate Solid Bullnose
FRONT AND SIDES
  • 11 Ga. Sheet
  • 11 Ga. One Piece Formed Dog House
  • 3” x4” x 11 Ga. Top Tube
  • 11 Ga. 3” x 5” Formed 4-way Bend Side Stiffener on 24” Centers. Columns have notches at bottom to prevent moisture retention
  • 11 Ga. Formed Corner Post wraps around for extra strength
REAR CORNER POST
  • Latch Side 3” x 4” x 11 Ga. Tube
  • Hinge Side 3” x 8” x 3/16” Formed Stiffener 4-way Bend
REAR DOOR
  • 11 Ga. Sheet w/ 3” x 4” x 11 Ga. Tube Frame and 3/8” Safety Chain
  • Hinges ½” x 9” x 9” and ½” x 3” x 9” Plates with 2” OD Mechanical Tube Bushings with Grease Fittings and one 3/16” Cold Rolled Pin
  • Non-Sagging Door is designed to rest on the fl oor of the container
DOOR LOCK
  • Semi-automatic Cam Locking system w/3 Cams & Self-Aligning Keeper and with a Vertical Lift Handle (fl at bar) to assure customer safety
ROOF
  • 11 Ga. Steel With Maximum of 4 openings per side for a total of 8 per container.
DIVIDER (OPTIONAL)
  • 11 Ga. Steel reinforced with 2” x 2” x 1/4” angle. Locking pins are inserted through the side of the container to lock divider in place.
  • Each divider has an 11 Ga. fi xed plate welded above to eliminate spillage into the next compartment. This enables you to obtain the fullest capacity of that compartment.

NOTE: Recycle Containers can be stacked 5 or 6 per load. This saves freight cost per container. However, when stacking and unstacking, doors have to be removed and re-hung, and the containers may be scratched or dented. We cannot be responsible for this happening since it is unavoidable when stacking containers.
